Technical Performance and Safety of the YR0241 Trinocular Microscope
Product Description
The YR0241 Trinocular Microscope is a state-of-the-art instrument designed to meet the advanced needs of laboratory professionals. This microscope features a Siedentopf trinocular head inclined at 30 degrees, providing users with a comfortable viewing angle. The interpupillary distance is adjustable between 55mm and 75mm, allowing for customized fit according to individual user preferences.
One of the standout features of the YR0241 is its thick and fine coaxial knob, offering a movement range of 24mm with a fine division of 0.004mm. This precision focusing mechanism is crucial for detailed observations and ensures that users can achieve the highest level of clarity and accuracy during their work.
The microscope is equipped with a quadruple revolving nosepiece, facilitating quick and easy switching between different objective lenses. The included achromatic objectives of 4x, 10x, 40x, and 100x provide versatility for various imaging needs, from low to high magnification.
The mechanical stage measures 132x142mm and features a secondary stage measuring 75x40mm, enabling users to hold and move samples securely without compromising on stability. Additionally, the Abbe NA1.25 condenser with an iris diaphragm and filter enhances light control, ensuring optimal illumination for the specimens being examined.
The YR0241 also features a 3W adjustable LED illumination system, which offers durability and an extended lifespan compared to traditional halogen bulbs. This illumination is essential for enhancing the visibility of samples under varying conditions.
Market Price
The YR0241 Trinocular Microscope is competitively priced at USD 168.00, making it an accessible option for laboratories seeking quality without breaking the bank. This price point reflects its advanced features and the reliability that comes with the Kalstein brand.
| Feature | YR0241 |
|---|---|
| Trinocular Head | Siedentopf, 30° inclination, 55-75mm interpupillary distance |
| Focusing Mechanism | Coaxial coarse and fine knob, 24mm movement range, 0.004mm fine division |
| Objective Lenses | Achromatic 4x, 10x, 40x, 100x |
| Illumination | LED 3W, adjustable brightness |
| Condenser | Abbe NA1.25 with iris diaphragm and filter |
Frequently Asked Questions
What is the maximum interpupillary distance of the YR0241 Microscope?
The maximum interpupillary distance of the YR0241 Microscope is 75mm, allowing for comfortable viewing for users with different eye distances.
What types of objective lenses come with the YR0241 Microscope?
The YR0241 Microscope comes equipped with four achromatic objective lenses: 4x, 10x, 40x, and 100x, covering a wide range of magnifications for various applications.
What type of light source does the YR0241 use?
The YR0241 uses a 3W LED light source that offers adjustable brightness, providing a reliable and energy-efficient illumination option.
What is the focusing mechanism of the YR0241 Microscope?
The microscope features a coaxial focusing mechanism with a coarse and fine knob that enables precise control over the focus with a movement range of 24mm and a fine division of 0.004mm.
Is the YR0241 suitable for professional laboratory use?
Yes, the YR0241 is designed for professional laboratory use, offering high-quality optics, precision mechanics, and durability that meet the standards of advanced microscopy applications.
What are the dimensions of the mechanical stage of the YR0241?
The mechanical stage of the YR0241 measures 132x142mm with an additional stage of 75x40mm, providing ample space for various sample sizes.
Pros and Cons
Pros:
- High-quality optics with achromatic objectives
- Adjustable interpupillary distance for comfort
- Precision focusing mechanism
- Durable LED illumination system
- Quadruple revolving nosepiece for quick changes between objectives
Cons:
- Limited to achromatic lenses, no apochromatic options
- Weight may be heavier compared to basic models
Field Usage
The YR0241 Trinocular Microscope is ideal for various fields, including biological research, educational institutions, and clinical laboratories. Its combination of optical clarity and mechanical precision makes it suitable for examining biological specimens, conducting educational demonstrations, and even performing routine laboratory analysis.
In educational settings, this microscope can provide students with hands-on experience in microscopy techniques, allowing for clearer understanding of cellular structures, microorganisms, and histological samples.
In clinical laboratories, the YR0241 is capable of providing accurate results for diagnostics and research, making it a valuable tool for pathologists and laboratory technicians. The adjustable light source also ensures flexible usage in different laboratory environments.
Recommendations
For users looking to enhance their microscopy experience, it is recommended to consider optional accessories such as additional eyepieces or a phase contrast kit that can expand the capabilities of the YR0241. Using these accessories can further improve image quality and enhance observation techniques.
Regular maintenance and calibration of the microscope are also recommended to ensure longevity and consistent performance. Users should keep the optical components clean and ensure that light sources are functioning correctly.
If you are interested in adding the YR0241 Trinocular Microscope to your laboratory collection, we invite you to request a quote for detailed pricing and availability.
