Technical Glossary and Key Terminology of the YR06215 Infant Incubator
The YR06215 Infant Incubator is a sophisticated medical device designed to provide a controlled environment for newborns. Understanding its terminology is essential for effective operation and maintenance. This article presents a detailed glossary of terms related to the YR06215, aiming to enhance user knowledge and equipment utilization.
Understanding the YR06215 Infant Incubator
The YR06215 is a state-of-the-art infant incubator that features a silent fan, adjustable temperature deviations, and multiple safety functions. Knowing the specific terms used in the context of this equipment is crucial for healthcare professionals who operate it daily.
Technical Specifications of the YR06215
| Feature | Specification |
|---|---|
| Model | YR06215 |
| Power Supply | AC110/220V 60/50Hz |
| Power Input | 450VA |
| Environment Temperature | 10°C~30°C |
| Relative Humidity | 30%~75% |
| Air Velocity | < 1m/s |
| Air Temperature Control Range | 25°C-37°C, 37.1°C~38°C |
| Skin Temperature Control Range | 32°C~37°C, 37.1°C-38°C |
| Temperature Sensor Accuracy | ±0.3°C |
| Temperature Fluctuation | ±1°C |
| Mattress Temperature Uniformity | ≤1.5°C |
| Air Temperature Deviation Alarm | ±3°C |
| Skin Temperature Deviation Alarm | ±1°C |
| Warm-up Time | ≤40min |
| Internal Noise Level | ≤60dB(A) |
| Main Battery | DC12V 40AH, Li-ion battery |
| Charge Time | 12 hours |
| Battery Use Time | 2 hours |
| Auxiliary Battery | DC8.4V 0.17AH, Li-ion battery |
| Mattress Size | 63cm(L) *32cm(W) |
| Trough Capacity | 1200mL |
| Air Filter | 0.5m |
Key Terminology Related to the YR06215
The following glossary provides definitions of essential technical terms associated with the YR06215 Infant Incubator:
| Term | Definition |
|---|---|
| Incubator | A device that provides a controlled environment for the care of premature or ill infants by regulating temperature, humidity, and oxygen levels. |
| Temperature Deviation | The variance in temperature settings that can be adjusted to ensure optimal thermal conditions for the infant. |
| Alarm System | A feature that alerts the operator to any deviations in temperature or humidity outside of the acceptable range. |
| Fan Operation | The mechanism that circulates air within the incubator to maintain uniform temperature and avoid hot spots. |
| Oxygen Supply | Provision of supplemental oxygen to the infant through dedicated outlets within the incubator. |
| Humidity Control | The ability to regulate moisture levels within the incubator to prevent dehydration of the infant's skin. |
| Skin Temperature Sensor | A device that monitors the actual temperature of the infant's skin to maintain appropriate thermal support. |
| Warm-up Time | The duration required for the incubator to reach the set temperature before placing the infant inside. |
| Mattress Temperature Uniformity | The consistency of temperature across the surface of the mattress to ensure even warmth distribution. |
| Power Input | The electrical consumption required by the incubator for operation, measured in VA. |
Frequently Asked Questions
What is the purpose of the YR06215 Infant Incubator?
The YR06215 Infant Incubator is designed to provide a safe and controlled environment for premature or ill infants. It regulates temperature, humidity, and oxygen levels to support the delicate needs of newborns during critical times.
How can the temperature deviation be adjusted on the YR06215?
Temperature deviation can be directly adjusted on the front panel of the YR06215, allowing operators to set specific parameters based on the infant's requirements.
What safety features does the YR06215 include?
The YR06215 includes a dual thermal disconnection feature for enhanced safety, ensuring that the incubator does not overheat. It also has a reliable alarm system for temperature and humidity deviations.
How is the YR06215 powered and what are its energy requirements?
The YR06215 operates on AC110/220V with a power input of 450VA. It includes both a main and auxiliary battery to ensure continuous operation even during power interruptions.
What is the significance of the skin temperature sensor in the YR06215?
The skin temperature sensor is crucial for monitoring the infant's skin temperature closely. This feature helps maintain optimal thermal conditions and can trigger alarms if temperatures fluctuate outside the set range.
What should be the preparation steps before using the YR06215?
Before using the YR06215, ensure that it is properly set up and calibrated. This includes checking power supply connections, ensuring the incubator is at the desired warm-up temperature, and verifying that all alarm systems are functioning correctly.
Where can I find spare parts for the YR06215?
Spare parts for the YR06215 can typically be sourced through authorized distributors or the manufacturer's service channels to ensure compatibility and quality.
