Portable Desktop spectrophotometer YR05487
Portable Desktop spectrophotometer YR05487 — Kalstein laboratory equipment with technical specifications, advanced features, and certified professional solutions for scientific use.
The Portable Desktop Spectrophotometer YR05487 from Kalstein offers cutting-edge precision in color measurement, making it indispensable across various industries including textiles, ceramics, plastics, and electronics. Equipped with dual-array silicon photodiode sensors and an imported whiteboard, the spectrophotometer guarantees a repeatability of ΔEab within 0.02, and internal error control up to 0.15. Users can choose customizable apertures of Φ4 mm and Φ8 mm, allowing for detailed analysis on both large and fluorescent samples. Its integrated positioning camera and a user-friendly 7-inch touchscreen facilitate effortless control over measurement areas, maximizing both efficiency and accuracy in every reading.
Market Price
The market price for the YR05487 is generally positioned between $8,900 and $9,900 USD, influenced by configuration selections and additional accessories like optional micro printers or rotating stands. Such an investment is strategic for companies aiming to enhance color accuracy within their production processes. You can easily obtain a personalized quote via the Kalstein Plus platform, which guarantees a seamless purchasing experience.
Frequently Asked Questions
- What industries benefit the most from using the YR05487?
This spectrophotometer is crucial for industries requiring precise color control, particularly in the textile, ceramics, and plastics sectors. - Does it integrate with PCs?
Yes, the YR05487 is compatible with PC software, allowing for comprehensive color management and analysis. - What is its data storage capacity?
It can store up to 1,000 standards and 20,000 samples, which is ideal for maintaining organized records.
Advantages and Disadvantages
The YR05487 boasts high precision and flexibility for measuring large and fluorescent samples. Its USB connectivity and Bluetooth 5.0 support efficient data transfer. However, its focus is primarily on laboratory applications, which might limit use in smaller workspaces or tasks not requiring such high precision.
Field Applications
This spectrophotometer is perfectly suited for quality control laboratories where precise color analysis is crucial. Its ergonomic design and versatile operation make it adaptable to various working conditions, enhancing measurement consistency and production efficiency with its quick 3.2-second SCI/SCE readings.
Recommendations
To ensure optimal performance of the YR05487, regular calibrations are advised, and it should be kept in a clean environment free from dust. Its full-spectrum LED and UV lighting enable precise measurements in diverse conditions. Request a tailored quote or generate one quickly through the Kalstein Plus platform to see how the Portable Desktop Spectrophotometer YR05487 can enhance your industry's color control and product quality.
Features
- Precise color measurement for large and fluorescent samples
- Advanced dual-array silicon photodiode sensors
- Customizable aperture settings for flexible measurements
- Large 7-inch touchscreen for easy visual control
- Robust data storage capabilities
- Comprehensive PC software compatibility
- Durable design with a long lifespan of illuminant
Technical Specifications
| Model | YR05487 |
| Optical Geometry | D/8(diffused illumination, 8-degree viewing angle) |
| SCI (specular component included)/SCE (specular component excluded) ; Include UV / excluded UV light source | |
| Comply to CIE No.15，GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7 | |
| Characteristic | Customized aperture, good for horizontal or vertical measurement, wider adaptability; |
| Suitable for precise color measurement and quality control in textile and garment printing and dyeing, plastic electronics, ceramics and other industries; | |
| Integrating Sphere Size | Φ40mm |
| Light Source | Combined full spectrum LED light source |
| Spectrophotometric Mode | Flat Grating |
| Sensors | Silicon photodiode array (double row 40 groups) |
| Wavelength Range | 400~700nm |
| Wavelength Interval | 10nm |
| Semiband Width | 10nm |
| Measured Reflectance Range | 0~200% |
| Measuring Aperture | Customized single aperture:MAV:Φ8mm/Φ10mm;SAV:Φ4mm/Φ5mm |
| Specular Component | SCI/SCE |
| Color Space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,s-RGB,βxy,Munsell(C/2) |
| Color Difference Formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1), ΔE*cmc(1:1),ΔE*00 |
| Other Colorimetric Index | WI(ASTM E313,CIE/ISO,AATCC,Hunter)， |
| YI(ASTM D1925,ASTM 313), | |
| Staining Fastness, Color Fastness, Color Strength, Opacity | |
| 8° Glossiness,555 tone classification | |
| Observer Angle | 2°/10° |
| Illuminant | D65,A,C,D50,F2(CWF),F7(DLF), F10(TPL5),F11(TL84),F12(TL83/U30) |
| Displayed Data | Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Simulation, Color Offset |
| Measuring Time | About 1.5s (Measure SCI & SCE about 3.2s) |
| Repeatability | Chromaticity value: MAV/SCI, within ΔE*ab 0.025 ( When a white calibration plate is measured 30 times at 5 second intervals after white calibration) |
| Inter-instrument Error | MAV/SCI, Within ΔE*ab 0.2 (Average for 12 BCRA Series II color tiles) |
| Measurement Mode | Single Measurement, Average Measurement(2-99times) |
| Locating Method | Camera Locating |
| Dimension | L*W*H=370X240X260mm |
| Weight | About 7.8kg |
| Battery | AC 24V, 3A Power adapter power supply |
| Illuminant Life Span | 5 years, more than 3 million times measurements |
| Display | 7-inch TFT color LCD, Capacitive Touch Screen |
| Data Port | USB, trigger switch interface |
| Data Storage | Standard 1000 Pcs, Sample 20000 Pcs |
| Language | Simplified Chinese, English, Traditional Chinese |
| Operating Environment | 0~40℃, 0~85%RH (no condensing), Altitude < 2000m |
| Storage Environment | -20~50℃, 0~85%RH (no condensing) |
| Standard Accessory | Power Adapter, USB Cable, User Guide, PC Software(Download from office website), White and Black Calibration Cavity, Protective Cover, Aperture (Optional Aperture) |
| Optional Accessory | Micro Printer, Foot Switch, Rotating Bracket |
| Notes | Technical parameters are only for reference, subject to the actual sale of the product |
Technical specifications
| Dimensions | L 45 × W 32 × H 35 cm |
|---|---|
| Weight | 12 kg |
| Manufacturer | Kalstein |
