Laboratory Biological Microscope YR0267A - YR0267B
Laboratory Biological Microscope YR0267A - YR0267B — Kalstein laboratory equipment with technical specifications, advanced features, and certified professional solutions for scientific use.
The Laboratory Biological Microscope YR0267A - YR0267B is a state-of-the-art optical instrument designed with the NIS Infinity Optical System, ensuring high contrast and exceptionally flat imaging. Equipped with a coded nosepiece, this microscope remembers illumination settings for each objective, optimizing light intensity and reducing visual fatigue. Perfect for professional laboratory settings, it provides outstanding resolution and a high signal-to-noise ratio, making it essential for precise scientific analysis.
Market Price
In today's market, the price range for a high-quality laboratory microscope like the YR0267A or YR0267B typically falls between $2,100 and $2,950 USD. This competitive pricing reflects the advanced features and superior imaging capabilities offered by these models.
Frequently Asked Questions
What is the difference between the YR0267A and YR0267B models?
The primary difference lies in the head configuration, with YR0267A featuring a Seidentopf Binocular Head, while YR0267B offers a Trinocular option, enhancing its functionality for imaging applications.
Can this microscope be used for phase contrast imaging?
Yes, both models are compatible with optional phase contrast accessories, allowing for versatile observational methods.
Advantages and Disadvantages
The YR0267A-B microscopes provide exceptional imaging clarity and versatility, suitable for diverse research applications. Advantages include coded illumination, high signal-to-noise ratio, and a wide field eyepiece. However, the initial cost and required maintenance may be considerations for budget-conscious laboratories.
Product Usage in the Field
In practice, these microscopes are widely used in biological research environments, providing researchers with clear, detailed visualization of samples. Their precision optical systems make them ideal for cellular and microbiological studies.
Recommendations
To ensure long-term durability and optimal performance, it's recommended to regularly clean the optical components and calibrate the nosepiece as necessary. Utilizing the Kalstein Plus platform, users can easily generate quotes and manage purchases for these advanced instruments.
Features
- NIS Infinity Optical System
- High Contrast and Flat Image
- Wide Field Eyepieces with Fn 22
- Coded Nosepiece for Memory of Illumination
- Compatible with Various Objective Methods
- Digital and Wireless Imaging Options
Technical Specifications
| Model | Cata. No. | YR0267A | YR0267B | |
| Optical System | NIS Infinite Optical System | ● | ● | |
| Observation Method | Bright Field | ● | ● | |
| Dark Field | ○ | ○ | ||
| Polarizing | ○ | ○ | ||
| Phase Contrast | ○ | ○ | ||
| Epi-Fluorscence | ○ | ○ | ||
| Head | Seidentopf Binocular Head, Inclined At 30° , Interpupillary Distance 47-78mm, Eyepiece Tube Dia.30mm | YR0267B-op1 | ● | |
| Seidentopf Trinocular Head, Inclined At 30° , Interpupillary Distance 47-78mm, Eyepiece Tube Dia.30mm, Light Path Fixed 50:50 | YR0267B-op2 | ● | ||
| Seidentopf Trinocular Head, Inclined At 30° , Interpupillary Distance 47-78mm, Eyepiece Tube Dia.30mm, Light Path Switchable 0:100/100:0 | YR0267B-op3 | ○ | ○ | |
| Tilting Binocular Head, Inclined 5°~35° , Interpupillary Distance 47-78mm, Eyepiece Tube Dia.30mm | YR0267B-op4 | ○ | ○ | |
| Digital Head, Built-in Digital Camera 5.0M, Support Android, IOS, Windows, Output Image By WIFI In Real Time | YR0267B-op5 | ○ | ○ | |
| Upgrade to A31.1062-5.0M | ||||
| Digital Head, Built-in Wireless Digital Camera 5.0M, Support Android, IOS, Windows, Output Image By WIFI In Real Time, App Software, By Scanning QR Code On Microscope, Installing App & Identifying Microscope, You Can View Micro Image On Mobile Phone & Tablet. | YR0267B-op6 | ○ | ○ | |
| Upgrade to A31.1062-5.0W | ||||
| Eyepiece | EW10x/22mm, Diopter Adjustable, Dia.30mm | YR0267B-op7 | ● | ● |
| EW15x/16mm, Diopter Adjustable, Dia.30mm | YR0267B-op8 | ○ | ○ | |
| EW20x/12mm, Diopter Adjustable, Dia.30mm | YR0267B-op9 | ○ | ○ | |
| Nosepiece | Quintuple Nosepiece, Dovetail Interface | YR0267B-op10 | - | - |
| Coded Quintuple Nosepiece, Dovetail Interface | YR0267B-op11 | ● | ● | |
| NIS45 | 4x/0.10, W.D.20.6mm | YR0267B-op12 | - | - |
| Infinity Plan | 10x/0.25, W.D.17.9mm | YR0267B-op13 | - | - |
| Objective | 20x/0.40, W.D.6.40mm | YR0267B-op14 | - | - |
| 40x/0.60, W.D.1.50mm | YR0267B-op15 | - | - | |
| 60x/0.80, W.D.0.30mm | YR0267B-op16 | - | - | |
| 100x/1.25(Oil), W.D.0.16mm | YR0267B-op17 | - | - | |
| 100x/1.10(Water), W.D.0.16mm | YR0267B-op18 | - | - | |
| NIS60 | 4x/0.10, W.D.30.0mm | YR0267B-op19 | ● | ● |
| Infinity Plan | 10x/0.25, W.D.10.2mm | YR0267B-op20 | ● | ● |
| Objective | 20x/0.40, W.D.4.8mm | YR0267B-op21 | ○ | ○ |
| 40x/0.65, W.D.1.5mm | YR0267B-op22 | ● | ● | |
| 60x/0.80, W.D.0.30mm | YR0267B-op23 | ○ | ○ | |
| 100x/1.25(Oil), W.D.0.3mm | YR0267B-op24 | ● | ● | |
| 100x/1.10(Water), W.D.0.2mm | YR0267B-op25 | ○ | ○ | |
| NIS60 | 10x/0.25, W.D.10.2mm | YR0267B-op26 | ○ | ○ |
| Infinity Plan | 20x/0.40, W.D.12.0mm | YR0267B-op27 | ○ | ○ |
| Phase Contrast | 40x/0.65, W.D.0.7mm | YR0267B-op28 | ○ | ○ |
| Objective | 100x/1.25(Oil), W.D.0.2mm | YR0267B-op29 | ○ | ○ |
| Focusing | Coaxial Coarse & Fine Adjustment, Tension Adjustable, Fine Division 0.002mm, Coarse Focusing Range 28mm | ● | ● | |
| Working Stage | Double Layer Mechanical Rackless Stage, Size 230x150mm, Moving Range 78x54mm | - | - | |
| Double Layer Mechanical Rackless Stage, Size 230x150mm, Moving Range 78x54mm, Anti-Scratch Hard Coating Dural Platform | ● | ● | ||
| Condenser | Inserted Abbe Condenser N.A. 1.25, With Slot For Phase Contrast Slide And Dark Field Slide. | ● | ● | |
| Illumination | 1W S-LED Critical Illumination | - | - | |
| 3W S-LED Kohler Illumination | ● | ● | ||
| Green Filter | ● | ● | ||
| Dark Field | Dark Field Slide | YR0267B-op29 | ○ | ○ |
| Polarizing | Simple Polarizing Set | YR0267B-op30 | ○ | ○ |
| Phase Contrast | Phase Slider For 10x-40x | YR0267B-op31 | ○ | ○ |
| Phase Slider For 100x | YR0267B-op32 | ○ | ○ | |
| Epi-Fluorescence Attachment | 3W LED Epi-Fluorescence Attachment, Fly-Eye Lens Illumination, With 2 Filter Position + Bright Field Position, Switch Quickly, With Attachable UV Shield, | YR0267B-op33 | ○ | ○ |
| B, G Filters | ||||
| Filter U | YR0267B-op34 | ○ | ○ | |
| Filter V | YR0267B-op35 | ○ | ○ | |
| Photo Adapter | 1.0x C-Mount | YR0267B-op36 | ○ | ○ |
| 0.5x C-Mount | YR0267B-op37 | ○ | ○ | |
| Power Supply | AC 100-240V,50/60Hz | ● | ● | |
| USB Charging Port, Support To Use Exeternal Rechargeable Battery Power Bank Like Mobile Phone Out Door Freely | ● | ● | ||
| LCD Screen | LCD Screen On Front Of Body, Display Using State Of Microscope, Including Magnification, Light Intensity, Standby Status, Set Power Off Timer 5 Mins to 8 Hours, And So On. | ● | ● | |
| Dimensions | 220(W)x290(D)x472(H) mm | ● | ● | |
| Note:"●"In Table Is Standard Outfits,"○"Is Optional Accessories"-"Is Unavailable | ||||
Technical specifications
| Dimensions | L 48 × W 32 × H 58 cm |
|---|---|
| Weight | 15 kg |
| Manufacturer | Kalstein |
Available models
Image gallery
Video Laboratory Biological Microscope YR0267A - YR0267B
Frequently asked questions
How to know the prices of Laboratory Biological Microscope YR0267A - YR0267B?
To know the price of Laboratory Biological Microscope YR0267A - YR0267B, please send us an email with your request through the contact form AQUI.
What are the delivery times for Laboratory Biological Microscope YR0267A - YR0267B?
Delivery time depends on stock availability and freight type (air or sea). In stock: air 15-30 days, sea 45-60 days. Out of stock: air 30-60 days, sea 60-90 days.
How to make a purchase of Laboratory Biological Microscope YR0267A - YR0267B?
You can buy by email ([email protected]), phone (+33 (0) 1 70 39 26 50) or through the official Kalstein website in your country.
How does the warranty work for Laboratory Biological Microscope YR0267A - YR0267B?
All Kalstein equipment comes with a 1-year warranty against manufacturing defects. The warranty does not cover damage from improper installation or misuse. See our «terms and conditions» AQUI.
Can I request a quote online for Laboratory Biological Microscope YR0267A - YR0267B?
Yes, you can request a quote for the Kalstein equipment you are interested in directly from our official website. Click AQUI.
