Description
The Biomedical Liquid Nitrogen Storage Solutions Dryshipper Series for Transportation (Round Canisters) YR05417 // YR05422 is expertly crafted to ensure the safe and efficient transport of biological samples under cryogenic conditions. Boasting an innovative design that facilitates vapor phase storage at temperatures below -190°C, these round canisters offer an unrivaled solution for air transportation of sensitive materials. The risk of liquid nitrogen (LN₂) spillage is entirely mitigated, thereby enhancing safety and reliability during transit. Constructed with rugged and durable aluminum, they promise longevity and robust performance.
Market Pricing
In the competitive field of cryogenic transportation solutions, the Biomedical Liquid Nitrogen Storage Solutions Dryshipper Series stands out not only for its specifications but also for its value. While the cost of such high-quality and durable products typically ranges between $1500 and $2300, it is recommended to request a personalized quote to get the best price tailored to your specific needs. Contact us or use the Kalstein Plus platform for an automatic quote today.
Frequently Asked Questions
What makes the Dryshipper Series suitable for air transportation?
The series is uniquely designed to prevent LN₂ spillages, making it exceptionally safe for air travel.
Can the canisters be locked for added security?
Yes, the canisters come with lockable lids to ensure the security of samples during transportation.
Advantages and Disadvantages
Among the key advantages of this product are its robustness and durable construction, vacuum warranty of three years, and its efficient LN₂ absorption, which ensures no spillages occur even if the tank is capsized. However, the initial investment may be higher than alternative solutions, though it is justified by enhanced safety features and long-term use benefits.
Field Application
In practical scenarios, these storage solutions are pivotal in maintaining the integrity of biological samples during transit. Ideal for laboratories and research facilities that require the transport of sensitive samples over long distances without compromising on temperature control.
Recommendations
To ensure the longevity and optimal performance of your Dryshipper canisters, always adhere to the manufacturer’s guidelines for use and maintenance. Regular checks on the vacuum seal and LN₂ levels can extend the life of the device significantly.
Features
- Safe and secure transportation of cryogenic samples
- Rugged aluminum construction
- Spillage-proof design
- Lockable lids for enhanced security
- Three-year vacuum warranty
Technical Specifications
| Model | YR05417 | YR05418 | YR05419 | YR05420 | YR05421 | YR05422 | |
| Maximum Storage Capacity | No. of Canister | 1 | |||||
| No. of Straws
(0.5ml / EA) |
132 | 374 | 854 | — | |||
| No. of Straws
(0.25ml / EA) |
298 | 837 | 1940 | — | |||
| No. of 2.0 ml Cryovials | — | 100 | 300 | 500 | |||
| No. of Boxes in( 2ml per holder) | — | 4 | 3 | 5 | |||
| Performance | Volume of LN (L) | 3 | 6 | 10 | 15 | 25 | |
| Absorbable Volume of LN2 (L) | 1.3 | 2.9 | 3.4 | 6 | 9 | ||
| Static Evapouration* (L/Day) | 0.16 | 0.2 | 0.43 | 1.5 | 0.89 | ||
| Liquid Phase Static Holding Time**(Day) | 20 | 37 | 23 | 10 | 29 | ||
| Liquid Phase Static Holding Time**(Day) | 8 | 14 | 8 | 4 | 10 | ||
| Dimensions | Opening Diameter (mm) | 50 | 80 | 125 | 216 | 216 | |
| Height (mm) | 435 | 487 | 625 | 540 | 716 | ||
| Outside Diameter (mm) | 223 | 300 | 300 | 394 | 394 | ||
| Canister Outside Diameter (mm) | 38 | 63 | 97 | — | |||
| Outside Height (mm) | 120 | 120 | 120 | — | |||
| Empty Weight (kg) | 3.2 | 4.9 | 6.7 | 8.5 | 15 | ||
| Full Weight (kg) | 4.7 | 7.5 | 11 | 25 | 30 | ||
| Shipping Weight (kg) | 5.5 | 7.7 | 9.7 | 15.2 | 20.5 | ||
| Additional Features | Includes 1 canister
(height 120mm), lockable cap and protective jacket |
Includes 1 canister
(height 120mm), lockable cap and protective jacket |
Includes 1 rack (4 layers),
5*5 cryoboxes, lockable cap and protective jacket |
Includes lockable cap
and protective jacket, no rack |
Includes 1 rack (3
layers), 9*9 cryoboxes and lockable cap, no protective jacket |
Includes 1 rack (5 layers),
9*9 cryoboxes and lockable cap, no protective jacket |
|
