Biological tissue freeze embedding machine {6 liters, with cooling plate} YR448

Manufacturer: Kalstein

Description

The Biological Tissue Freezing Embedding System YR448 is an advanced tool designed for histology laboratories that require precision and efficiency. Featuring an imported OLED screen, this system offers clear and readable data from any angle. Moreover, the user interface is intuitive, with work status icons and button LEDs clearly indicating the operational status.

This fully automated system allows users to schedule on and off times at any moment during the week, providing total flexibility. It uses a high-precision temperature measurement block made in the United States and a seven-channel independent PID temperature control. Each channel operates without interference. Additionally, the new flexible heating element ensures rapid and uniform heating, offering significant energy savings.

Market Price

The Biological Tissue Freezing Embedding System YR448 is competitively priced. Generally, it ranges between $5,000 and $7,000, depending on the supplier and additional specifications. This investment is justified by the precision and efficiency it brings to the tissue embedding process.

Frequently Asked Questions

  • What is the temperature range of the cryogenic module?

The temperature range of the cryogenic module is from 0 to -20°C.

  • How is the temperature of the cryogenic module controlled?

The system automatically adjusts the temperature to maintain an optimal working temperature of around -10°C, with delay protection for added safety.

  • What are the dimensions of the cryogenic module?

The dimensions of the cryogenic module are 315×380 mm.

Advantages and Disadvantages

Advantages:

  • High precision: The system offers exact temperature control with PID technology.
  • Energy efficiency: Flexible heating elements ensure significant energy savings.
  • Complete automation: Users can schedule automatic on and off times weekly.

Disadvantages:

  • Initial cost: The price can be significant for some laboratories.
  • Space required: The equipment’s dimensions may require considerable space in the laboratory.

Field Use

The Biological Tissue Freezing Embedding System YR448 is mainly used in histology laboratories for embedding and freezing biological samples. Its ability to maintain precise temperatures and programmable control makes it ideal for demanding work environments, ensuring consistent and high-quality results.

Recommendations

To maximize the performance of the YR448, perform regular maintenance, focusing on the temperature sensors and heating elements. Additionally, training personnel in the proper use of the programmable control and automatic functions will ensure the equipment’s longevity and optimal results.

Don’t miss the opportunity to improve your laboratory’s efficiency and precision. Request a quote or generate an automatic quote through the Kalstein Plus platform. Discover how the Biological Tissue Freezing Embedding System YR448 can transform your embedding and freezing processes. Optimize your results today and take your analysis precision to the next level with the Biological Tissue Freezing Embedding System YR448.

Technical description

Model YR448
Cryo module temperature ranges 0 a -20 C
Cryo module temperature setting The optimal working temperature is
about -10 C, and the temperature
is under delay protection
Cryo module dimensions 315×380 mm.
Working voltage
CA 220V +/- 10% 50Hz (Standard Model); AC110V +/- 10% 60Hz
Power 300W
Dimensions 710x350x390mm (WxDxH)
Net Weight 25kg

Additional information

Weight 116 kg
Dimensions 85 × 123 × 71 cm
