Microscope Trinocular YR0242-M: Practical Laboratory Use
The Trinocular Microscope YR0242-M is an essential tool for laboratories, designed to provide high-quality optical performance and user-friendly features. This microscope is equipped with a range of advanced specifications that cater to the diverse needs of researchers and educators alike. Its innovative design allows for enhanced imaging capabilities while maintaining ease of use.
Product Description
The YR0242-M model offers a selection of monocular, binocular, trinocular, and teaching heads, each angled at 30 degrees and rotatable 360 degrees. This flexibility allows users to find the most comfortable viewing position. Additionally, both the binocular and trinocular eyepieces are equipped with adjustable diopters (+/-5) to ensure optimal focus for different users.
One of the standout features of this microscope is its quadruple nosepiece, which includes precise click stops for easy objective changes. The integrated double-layer mechanical stage measures 142x132mm, providing a movement range of 75x50mm, which is ideal for maneuvering samples during observation.
The microscope also includes an Abbe condenser with a numerical aperture of 1.25 and a high-brightness 3W LED light source, which is adjustable for brightness. This combination of features guarantees excellent illumination and clarity, making it suitable for various applications.
Market Price
The YR0242-M microscope is competitively priced at approximately $152.00 USD, making it an affordable option for educational institutions and research facilities looking to enhance their laboratory capabilities without compromising on quality.
| Feature | YR0242-M | YR0242-B |
|---|---|---|
| Head Type | Trinocular | Binocular |
| Objective Lenses | 4X, 10X, 40X(S), 100X(O,S) | 4X, 10X, 40X(S) |
| Condenser NA | 1.25 | 1.25 |
| Illumination Type | LED 3W | Halogen |
| Focusing Type | Coaxial Fine and Course | Coaxial Fine and Course |
| Stage Size | 142x132mm | 132x142mm |
Frequently Asked Questions
What is the maximum magnification of the YR0242-M?
The maximum magnification of the YR0242-M is 1000x, achieved using the 100x oil immersion objective lens paired with a suitable eyepiece.
Is the illumination adjustable?
Yes, the YR0242-M features an adjustable brightness LED illumination system, allowing users to optimize light levels for various sample types.
What types of samples can be observed with this microscope?
The YR0242-M is suitable for a range of sample types, including biological specimens, slides, and educational demonstrations, making it versatile for various laboratory applications.
Can the microscope be used for teaching purposes?
Absolutely! The trinocular head is specifically designed to facilitate teaching, allowing students to observe alongside the instructor without compromising the viewing experience.
Is there a warranty included with the microscope?
Typically, microscopes like the YR0242-M come with a manufacturer's warranty that covers defects in materials and workmanship. It is advisable to check specific warranty details at the time of purchase.
What is the weight of the YR0242-M microscope?
The YR0242-M microscope has a shipping weight of approximately 6 kg, making it portable yet stable for laboratory use.
Pros and Cons
Pros:
- Versatile trinocular head suitable for educational and research environments.
- High-quality optics providing clear and bright images.
- Adjustable illumination for various types of specimens.
- Affordable price for the features offered.
- Easy to use with user-friendly adjustments and controls.
Cons:
- The 100x objective requires oil immersion, which may not be suitable for all users.
- Some users may find the weight cumbersome for extensive mobility.
Field Usage
The YR0242-M microscope is applicable in various laboratory settings, including educational institutions, research facilities, and quality control labs. It serves as an excellent teaching tool for biology classes, allowing both instructors and students to engage in hands-on learning.
In research laboratories, the microscope is ideal for observing microorganisms, cellular structures, and tissue samples. The high magnification capability, coupled with excellent lighting options, supports detailed examinations necessary for scientific inquiry.
Furthermore, industries that require quality control processes can benefit from the YR0242-M's reliable optical performance for inspecting raw materials and finished products.
Recommendations
For those considering the purchase of the YR0242-M microscope, it is recommended to evaluate the specific laboratory needs to determine if a trinocular model suits your application. Additionally, investing in quality slides and coverslips will enhance the viewing experience. It is also advisable to familiarize oneself with the microscope's adjustments for optimal use, potentially taking advantage of available training resources.
For more information or to request a quote on the YR0242-M microscope, please reach out. Our team is available to assist you with any inquiries.
